Battery Management SOC System On Chip Single Cell Lithium Ion Charger BQ24090DGQR


Price	consult with
MOQ	10
Delivery Time	5-8DAY
Brand	TI
Place of Origin	CN
Certification	ROHS
Model Number	BQ24090DGQR
Packaging Details	T/R
Payment Terms	T/T,Western Union
Supply Ability	100000

Product Details

Product Specification

Package / Case:	MSOP-10	Place of Origin	CN
Packaging:	Cut Tape	Packaging Details	T/R
Battery Type:	Lithium-ion	Factory Pack Quantity:	2500
Operating Supply Voltage:	4.5 V to 6.5 V	Model Number	BQ24090DGQR
Supply Ability	100000	Certification	ROHS
Brand Name	TI	Payment Terms	T/T,Western Union
Product Category:	Battery Management	Price	consult with
Delivery Time	5-8DAY	Series:	BQ24090
Minimum Order Quantity	10

Product Description

Battery Management IC - BQ24090DGQR

Battery Management Applied To Single-cell Lithium-ion Lithium-polymer Batteries And Charger Chips BQ24090DGQR

Product Overview

The BQ24090DGQR is a highly integrated lithium-ion and lithium-polymer battery charger designed for space-constrained applications. This single-cell charger supports USB port or AC adapter power sources with comprehensive protection features.

Key Specifications

Attribute	Value
Product Category	Battery Management
Battery Type	Lithium-ion/Lithium-polymer
Series	BQ24090
Package	MSOP-10
Operating Voltage	4.5 V to 6.5 V
Output Voltage	4.2 V
Output Current	1 A
Operating Temperature	-40°C to +150°C

Key Features

Precision Charging: 1% voltage accuracy, 10% current accuracy
Input Options: 100mA/500mA USB current limits
Comprehensive Protection: 6.6V overvoltage, thermal regulation (125°C), shutdown (150°C)
JEITA Compliance: Temperature monitoring via battery NTC
Compact Design: 10-pin MSOP package (3mm × 3mm)
